PVB/SGP Film Extrusion Line
USEON supplies the complete PVB / SGP film extrusion line, from feeding to winder, including the on-line crushing system. A twin screw extruder mixes the many additives of the formula into the polymer and extrudes the film directly.
- PVB
- SGP
500 kg/h PVB film extrusion line, seen from the winder
The film and its formula
PVB / SGP film production involves many sorts of additives, so it asks for an extruder that mixes and disperses well.
| Specification | PVB / SGP film |
|---|---|
| Film width | up to 4,000 mm |
| Film thickness | 0.3–1.5 mm |
| Max. output | 300–600 kg/h |
| Basic formula | PVB or SGP, additives, and on-line waste material |
Why a twin screw extruder
The mixing and dispersing ability of the twin screw extruder distributes the additives thoroughly and evenly into the polymer. Additives are saved, and the inner quality of the final film is raised.
The line, from feeding to winder
Four points in the line are specific to PVB and SGP.
- Feeding system with cooling jacket
- Twin screw extruder
- Co-extruder for the colour edge
- Automatic T-die
- Thickness tester
- Winder
On-line crushing system: the waste material of the line is crushed on line and is part of the formula again.
Cooled feeding
A special cooling jacket for the feeding system avoids choking due to the stickiness of the raw material.
Mixing and degassing
Twin screw extruder for better mixing and degassing performance.
Two colours
Co-extrusion for a second colour on the edge of the film.
Thickness in a closed loop
Automatic T-die, interlocked with the thickness tester.
Where the film goes
PVB interlayer film sits between two panes of glass.
Good adhesion to inorganic glass
Transparency, heat resistance, cold resistance, humidity resistance and high mechanical strength.
Construction, automotive, photovoltaic
PVB interlayer film is widely used in these and other industries.
With a special formula
The film is also used in aerospace, military and high-tech industries: aircraft, aerospace products, military instruments, solar cells and solar receivers.
Reference project
500 kg/h PVB Film Extrusion Line
- Output
- 500 kg/h
- Extruders
- SAT75 + SAT40, co-extrusion
- Application
- PVB film for laminated glass
Get a quote
Tell us the film you want to make. We propose the extruders and the line width.
- 01PVB or SGP; film width and thickness range
- 02Output per hour; clear film or with a colour edge
- 03Line configuration and quotation
